DP 580 / DP 585 DMR Portable Radio

As a DMR mobile radio with fashionable design, total functionality, DM588 brings extraordinary experience of digital communication in variety of scenarios such as taxis, truck, agriculture, delivery, school bus, and Ambulance.


User Manual

Download

Brochure

Download

Feature

Compact & Lightweight
The size of DP580 is 115mm*54mm*34mm and weight is 317g. The size of DP585 is 115mm*54mm*30mm and weight is 305g.

Reliable Design
It is compliant with MIL-STD-810 C/D/E/F/G standards.

DMO support
It provides Direct Mode Operation in 2 slots increasing channel capacity without increasing channel frequency spectrum.

Analog, Digital and Mixed Modes
DP580 and DP585 can detect signal type when receiving a call and automatically switch between analog and digital mode. The user can reply during the call hang time using PTT. This feature improves migration from analog to digital.

Secure Communication (Digital encryption)
It supports ARC 40-bit encryption, which guarantees communication safety and improves communication privacy. Encryption function provides further protection against over-the-air interception. It also provides AES and DES optionally.

Various Digital Signaling
It supports features such as Radio Check, Call Alert, Stun/Revive, Radio Kill, and Remote Monitor, which make radio management easy.

Emergency call and Man Down (Optional)
It supports features including Emergency Call and Man Down to guarantee user’s safety at all times.

GPS localization(Optional)
Integrated GPS enables the real time tracking of the mobile working team.

Advanced analog Signaling
It supports multiple advanced analog signaling, including MDC1200, 2-Tone and 5-Tone and DTMF, providing better integration for existing analog radio fleets.

Roaming
Automatic roaming helps you to use the radio freely among all sites on an IP Multi-Site Connect system.

Specification

GENERAL

Frequency Range 136-174MHz,350-400MHz,
400-470MHz
Channel Capacity 256
Zone Capacity 16
Channel Spacing Analog:25kHz/12.5kHz,
Digital:12.5kHz
Operating Voltage DC 7.4V±20%
Battery 2000mAH Li-ion(Standard)
Battery Life
(5-5-90 Duty Cycle,Hign Tx Power)
Analog:15 hours@2000mAh
Digital:17 hours@2000mAh
Frequency Stability ±0.5ppm
Antena Impedance 50Ω
Dimensions(H·W·D)
(with standard battery,without antenna)
115mm*54mm*34mm DP580
115mm*54mm*30mm DP585
Weight
(with standard battery)
DP580:317g(2000mAh)
DP585:305g(2000mAh)

RECEIVER

Sensitivity Analog
Digital
0.22uV@12dB SINAD
0.22uV@BER5%
Selectivity 60dB@12.5kHz,70dB@25kHZ(TIA-603)
TIA-603 ETSI 60dB@12.5kHz,70dB@25kHz(ETSI)
Spurious Response Rejection 70dB@12.5kHz/25kHz(TIA-603)
TIA-613 ETSI 70dB@12.5kHz/25kHz(ETSI)
Inter-modulation 70dB@12.5kHz/25kHz(TIA-603)
65dB@12.5kHz/25kHz(ETSI)
FM Hum and Noise 40dB@12.5kHz,45dB@25kHz
Rated Audio Power Output 1W
Rated Audio Distortion 3%(typical)
Audio Response +1~-3dB
Conducted Spurious Emission -57dBm@<1GHz,-47dBm@>1GHz

TRANSMITTER

RF Power Output VHF:1W/5W,UHF:1W/4W
FM Modulation 11KΦF3E@12.5kHz,16KΦF3E@25kHz
4FSK Digital Modulation 7K6ΦFXD@Data;7K6ΦFXW@Data+Voice
Modulation Limiting ±2.5kHz@12.5KHz,±5kHz@25kHz
Radiated Spurious Emission -36dBm < 1GHz, -30dBm > 1GHz
FM Hum & Noise 40dB@12.5kHz, 45dB@25kHz
Adjacent Channel Power 60dB@12.5kHz, 70dB@25kHz
Audio Response +1~-3dB
Audio Distortion 3%
Digital Vocoder Type AMBE+2™
Digital Protocol ETSI-TS102 361-1,-2,-3

ENVIRONMENT SPECIFICATIONS

Operating Temperature -30℃~ +60℃
Storage Temperature -40℃~+85℃
ESD IEC610000-4-2(Level4)
±4kV(Contact) ±8kV(air)
American Military Standard MIL-STD-810-C/D/E/F/G
Dust & Water Protection IP66 Standard
Humidity Per MIL-STD-810 C/D/E/F/G Standard
Shock & Vibration Per MIL-STD-810 C/D/E/F/G Standard

GPS

TTFF(Time To First Fix) Cold Start <1 minute
TTFF(Time To First Fix) Hot Start 10 seconds
Horizontal Accuracy 10m

Accessory

AC Adapter

Single Battery Charger

Multi Battery Charger

Battery

Standard
High Capacity

Belt Clip

Antenna
